J 100 LED LIGHT SOURCE MICROSCOPE |
|
Super LED illumination greatly extending the life of the illumination system. New anti-mold, damp-proof optical system is adopted to meet different changing environments. High bright, non-spherical illumination system. New digital camera system expends the observing ways. No overheating problems in the base. Long life-span LED lamp removes the trouble to replace light bulbs frequently. Optional build in high-capacity rechargeable battery provides 50 hours working without power supply. |
|
TECHNICAL SPECIFICATION OF J 100 |
|
NILPA CONSULTANCY |
|
2B-SHOBHANA APARTMENT, K V ROAD, OFF W S ROAD, DAHISAR (EAST) MUMBAI - 400 068 INDIA |
|
Specification |
J101 |
J102 |
J103 |
J104 |
|
|
Optical System |
Finity Optical System |
● |
● |
● |
● |
|
Viewing Head |
Mono Head ,Inclined at 30°,Rotatable 360 |
● |
|
|
|
|
Seidentopf Binocular Head, Inclined 30°,Rotatable 360°, Interpupilary Distance 50~75mm |
|
● |
● |
|
|
|
Seidentopf trinocular Head,Inclined 30°,Rotatable 360°, Interpupilary Distance 50~75mm |
|
|
|
● |
|
|
Eyepiece |
WF10X/18 mm |
● |
● |
● |
● |
|
Objective |
Achromatic 4X/0.10 W.D.=13mm |
● |
● |
|
○ |
|
Achromatic 10X/0.25 W.D.=6.3mm |
● |
● |
|
○ |
|
|
Achromatic 40X/0.65 (S) W.D.=0.44mm |
● |
● |
|
○ |
|
|
Achromatic 100X/1.25 (S,Oil) W.D.=0.3mm |
● |
● |
|
○ |
|
|
Plan Achromatic 4X/0.10 W.D.=16mm |
|
|
● |
● |
|
|
Plan Achromatic 10X/0.25 W.D.=2mm |
|
|
● |
● |
|
|
Plan Achromatic 40X/0.65 (S) .D.=0.66mm |
|
|
● |
● |
|
|
Plan Achromatic 100X/1.25 (S,Oil) .D.=0.42mm |
|
|
● |
● |
|
|
Nosepiece |
Quadruple, outward |
● |
● |
● |
● |
|
Stage |
Stage Size: 115×125mm, Moving range: 50×70mm |
● |
● |
● |
● |
|
Dark Field Ring |
Available for 4X-40X |
○ |
○ |
○ |
○ |
|
Condenser |
Abbe N.A. 1.25 with Iris Diaphragm, |
● |
● |
● |
● |
|
Illumination |
Incandescent Lamp 110V/220V, 20W Spare Lamp: 1pc Built In Blue Filter |
|
|
|
|
|
Halogen Lamp 6V 20W Wide Voltage: 80V~265V Spare Lamp: 1pc Built In Blue Filter |
○ |
○ |
○ |
○ |
|
|
LED Illumination Systems |
● |
● |
● |
● |
|
|
Fuse |
Spare Fuse: 2pcs |
● |
● |
● |
● |
