 T 500  TISSUE CULTURE INVERTED MICROSCOPE

500 inverted biological microscope is the potent guarantee of your success.  Excellent universal infinity independent plan achromatic optical system provides you with a high  quality imaging. T 500 inverted biological microscope provides a flexible upgrade path to meet your applications for observations of phase contrast, fluorescence, polarization, digital and photographing easily, and also can work with heat stage, patch clip, assistant stage harmonious. The adapter can connect various kinds of camera and digital observe device. 72mm ultra-long working distance condenser provides enough space for culture dish. Ergonomic machine design can make you work easily for a long time.

NILPA CONSULTANCY

2B-SHOBHANA APARTMENT,

K V ROAD, OFF W S ROAD,

DAHISAR (EAST)

MUMBAI - 400 068

INDIA



Phone:+91 22 2828 2830

Fax: +91 22 2828 0397

E-mail: info@nilpaconsultancy.in

Specifications

T 500

Optical System

Infinite Plan Optical System F=200mm

Viewing Head

Interpupillary distance 52~75mm,45° inclined,diopter adjustable. Seidentopf trinocular head which is at the side of the main frame can be worked with digital camera and computer. It doesn't influence the binocular observation.

trinocular light is split 50/50 by a high quality prism.(20/80 is for optional)





EYEPIECES

WF10X/20, High eye-point up to21mm.

●●

WF10X/22, High eye-point up to21mm.

○○

WF16X/14mm

○○

WF10X/20(Pointer), High eye-point up to21mm.

WF10X/22(Pointer), High eye-point up to21mm.

Reticule eyepiece: CROSSWF10X/20High eye-point up to21mm.

Reticule eyepiece: CROSSWF10X/22High eye-point up to21mm.

Nosepiece

Quintuple, Inward facing.

Centering Telescope

CTE

Objectives

Plan Achromatic 4X/0.13  WD=12.86mm

Plan Achromatic 10X/0.25  WD=9.67mm, 20X/0.40  WD=7.97mm, 40X/0.60  WD=3.76mm

Plan Achromatic Positive Phase-Contras 10X/0.25  WD=9.67mm

Plan Achromatic Positive Phase-Contras 20X/0.40  WD=7.97mm

Plan Achromatic Positive Phase-Contras 40X/0.60  WD=3.76mm, 10X/0.25  WD=9.67mm, 20X/0.40  WD=7.97mm, 40X/0.60  WD=3.76mm

Stage

Fixed stage: 240×260mm, low-position co-axial flexible adjusting handle, moving range: 135mm×85mm,

Slide Plate(Φ118mm), replaceable

Slide Plate(76×26mm, Φ60mm), replaceable

Mechanical stage: 350×208mm, moving range: 50×50mm, low-positioned coaxial flexible adjusting handle.

Condenser

72mm Extreme long work distance condenser, NA0.3, with iris diaphragm, 6V 30W halogen lamp house, filter jack.

Illumination

Phase-contrast slide makes it easy to change between 10X, 20X, 40X phase contrast and bright field observation.

6V 30W Osram halogen lamp

External power, wide voltage (100V~240V)

Fuse tube: 250V/3.15A Φ5×20

Filter

Blue filter (Φ34mm), Green filter (Φ34mm), Yellow filter (Φ34mm)

C-Mount

1X, 0.5X, 0.25X (Fit 1/3"CCD)

Digital Camera Joint

(Please advice your digital camera model in advance), PLEASE SEE THE DETAILS OF CAMERA IN CCD CAMERA
